3C8

Fracture of the tibial shaft treated with TL-HEX.

Equipment required
Q.tyCatalogue N.Description
2

56-20020



FULL RING, 160MM, TL-HEX

4

54-11640



TL+ FIVE HOLE POST

4

54-1152



TL,BOLT, WIRE FIXATION, UNIVERSAL

4

54-11530



TL+ UNIVERSAL HALF PIN FIXATION BOLT 4MM - 6MM

2

54-1215



TL,WIRE, W/STOPPER, 1.8MM X 400MM

4

54-1125



TL,HALF PIN, TAPERED, SELF THREADED, 6MM X 180MM

6

50-10400



LONG STRUT TL-HEX - 158MM-318MM

1

50-10215



STRUT NUMBER CLIP KIT, TL-HEX (6 PCS)

1

50-10214



STRUT DIRECTION CLIP KIT, TL-HEX (6 PCS)

4

54-1050



TL,BOLT, 12MM

8

50-1008



TL, NUT, STAINLESS STEEL, 10MM
